Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: OEM
  • Model Number: FD160GF
  • Output Type: AC Three Phase
  • Speed: 1500rpm
  • Frequency: 50HZ
  • Rated Power: 160KW/200KVA
  • Rated Voltage: 400/230V
  • Rated Current: 288A
  • Engine: Yuchai
  • Alternator: Marathon,Stamford,Stanford,Mecc Alte
  • Controller: Smartgen,Deepsea,Comap
  • Certificate: ISO9001:2008 CE
  • Warranty: one year or 1000 hours which comes first
  • Color: According to customers' Requirement
  • Control panel: Digital
  • Cooling Method: Water cooled
  • Type: Open Frame
  • Options: Silent/ ATS/Trailer

Packaging & Delivery

Packaging Details: Steel Cage or wooden cage
Delivery Detail: Shipped in 10 days after payment

200Kva diesel generator price from China

 The advantage of 200Kva Yuchai Engine genset
1. International Warranty Service
2. Short delivery time, as we always have Yuchai engine in stock
3. With CE/ISO9001 certification
4. Spare parts are easy to get from worldwide market with much cheaper price
5. Coupled with Stamford alternator, Marathon alternator or Chinese Megaton /Engga alternator
6. Perfect after-service network
7. Both 50Hz and 60Hz
8. Rigorous test including 50% load,75% load,100% load and 110% load

Our Service Quality Assurance:
1) Before-sale Service: we provide detailed product technical parameters for equipment choosing and system designing
2) Service quality assurance: our sale staffs are all experience and professional, who can provide the most proper system design and optimized equipment for the customers.
3) After sale maintenance service: We create files for end user and provide them follow-up service, regular return visit and permanent maintenance.



Generator Specilizations

Technical data

Genset Model

FD160GF

 Prime Power

160KW/200KVA

Rated Voltage

220V

Frequency

50Hz

Power Factor

0.8(lagging)

The regulating rate of steady voltage

≤±0.5%

The regulating rate of instantaneous voltage

≤-15%/ +20%

The time of steady voltage

≤1.5sec

The waving rate of voltage

≤1.0%

The regulating rate of steady frequency

≤3%

The regulating rate of instantaneous frequency

≤±10%

The time of steady frequency

3sec

Dimension (L×W×H) (mm)

2600*1100*1650

Genset weight (kg)

1500

Diesel Engine

Brand

Yuchai

Model

YC6G245L-D20

Number of Cylinders

6

Rotating Speed

1500 RPM

Cycle

Four stroke

Type

waste gas turbine boost,direct spurting type

Bore×Stroke(mm)

112*132

Displacement(L)

7.8

Lubricating Capacity(L)

25

Speed Governor

Electrical

Cooling System

Water-cooled

Speed Stability (%)

≤5%

Fuel Consumption at 100% Load

200g/kw.h

Starting Method

DC24V Electrical starting

Alternator

Brand

Marathon,Stamford,Stanford,Mecc Alte

Model

FDF160

Number of Phase

3

Connecting Type

Three Phase and Four Lines

Number of Bearing

1

Grading Protection

IP23

Altitude

≤1000m

Exciter Type

Brushless (AVR automatic voltage regulating)

Insulation Class

H degree













 Qingzhou Feida Industrial CO.,LTD

    As one of the famous generator sets manufacturer in China,with its own production,R&D and sales facilities is OEM partner and service agent of CUMMINS,PERKINS,VOLVO, MTU, DEUTZ,HND-MWM,and DAEWOO and Chinese domestic brand like, Yuchai,Shangchai, Jichai,Weichai,Matching with the alternator,like,Stamford,Marathon,Siemens, Kangfu,Engga,and ourself brand-Walter.We also design and produce soundproof canopy type,Standard container type,low noise type and mobile trailer type,usedforland,marine,mine,oilfield, expressway, bank telecommunication,power station etc

1. Our Factory





2. Our Workshop









3. Our Delivery







4. Our Certificates









5. We attended 2016 Middle East Electricity Exhibition.



6. Customers from all over the world





8.FAQ

1.What is your warranty period?

  Our payment terms is 1 year or 1500 running hours whichever comes first. But based on some special project, we can extended our warranty period.



 2.  Does your generator have global warranty?

  Yes, most of our products like Cummins, Perkins, Doosan, Yuchai, Deutz, Volvo power generator enjoy the global warranty service. And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.

  3.Can you accept OEM?

 Yes, we can accept OEM.

 4. What is your payment  terms?

  We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.

   5.  What is your delivery time?

  Our normal delivery time is 7-10 days. But if your order is some special engine and alternator,

 then the delivery time is longer
